Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振
频率：100MHz
尺寸：3.2mm×2.5mm
Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振,Silicon晶振,Si501进口晶振,有源晶体振荡器,501JCA100M000CAG晶振,石英晶振,四脚晶振,3225贴片晶振,频率100MHz,电压3.3V,频率稳定性20ppm,工作温度-40~85°C,高可靠性晶振,小体积晶振,低老化晶振,6G模块晶振,电机控制晶振,流量控制晶振,办公室自动化晶振.
订购热线：0755-27876565
Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振,Silicon晶振,Si501进口晶振,有源晶体振荡器,501JCA100M000CAG晶振,石英晶振,四脚晶振,3225贴片晶振,频率100MHz,电压3.3V,频率稳定性20ppm,工作温度-40~85°C,高可靠性晶振,小体积晶振,低老化晶振,6G模块晶振,电机控制晶振,流量控制晶振,办公室自动化晶振.
Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振特点：
-宽频率范围:32KHz至100MHz
-有关100 MHz以上的频率，请联系Silicon Labs
-Si501单频w/ OE
-Si502双频w/ OE/FS
-Si503四频w/ FS
-±20/30/ 50ppm频率稳定性，包括10年老化
-LVCMOS输出
-低周期抖动
-低功耗
-连续供电电压范围:+1.71 V ~ +3.63 V
-用户可选择的升降选项
-无故障启动和停止
-短期稳定性好，长期老化性好
-行业标准脚印:2x2.5, 2.5x3.2, 3.2x5 mm
-符合RoHS标准，无铅
-缩短交货期:<2周
-20至+70°C:扩展商用
-40至+85°C:工业
-Si50x系列还包括Si504，用于电路可编程性(参见Si504数据表)
Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振规格表
Parameters
Condition
Si501
Frequency Range
100MHZ
Frequency Stability
±20ppm
Operating Temperature
Extended Commercial grade
-20°C~+70°C
Extended commercial
-40°C~+85°C
Storage Temperature
-55°C~+125°C
Supply Voltage
3.3V
Supply Current
CL=4 pF, 3.3 VDD, FCLK=1.0 MHz, low power option
2.5 mA Max
CL=4 pF, 3.3 VDD, FCLK=100 MHz, low power option
6.5 mA Max
CL=4 pF, 3.3 VDD, FCLK=1.0 MHz, low jitter option
4.9 mA Max
CL=4 pF, 3.3 VDD, FCLK=100 MHz, low jitter option
8.9 mA Max
OE Internal Pull Resistor
Ordering option
60 kΩ Max
Rise and Fall Times 1
1st ordering option code2: A and H Z0=25 Ω@ 3.3 V
1.2ns Max
Startup Time2
From VDD crossing 1.71 V to first clock output
4ms Max
Output High Voltage
1st ordering option code: A and H IOH=–4 mA
0.90 x VDD Min
Output Low Voltage
1st ordering option code: A and H IOH=+4 mA
0.10 x VDD Max
Duty Cycle
Drive strength selected such that tRise/tFall (20% to 80%)<10% of period
45% Min ~55% Max
Period Jitter
100 MHz, Low Jitter Option 1st ordering option code: H
1.6 ps RMS Max
100 MHz, Low Power Option 1st ordering option code: A
1.9 ps RMS Max
Phase Jitter
75 MHz FOFFSET=900 kHz to 7.5 MHz Low Jitter Option 1st ordering option code: H
1.3 ps RMS Max
75 MHz FOFFSET=900 kHz to 7.5 MHz Low Power Option 1st ordering option code: A
3.2 ps RMS Max
Silicon品牌|501JCA100M000CAG|3225mm|6G模块晶振尺寸图
