Silicon品牌|500DLAA125M000ACF|6G无线通信晶振
频率：125MHz
尺寸：5.0mm×3.2mm
Silicon品牌|500DLAA125M000ACF|6G无线通信晶振,Silicon晶振,Si500D有源晶振,500DLAA125M000ACF晶振,LVDS输出晶振,石英晶体振荡器,进口贴片晶振,SMD晶振,5032mm晶振,频率125MHz,电压2.5V,频率稳定性150ppm,工作温度0~70°C,低抖动晶振,无铅环保晶振,高可靠性晶振,6G无线通信晶振,调制解调器晶振,医疗电子设备晶振,智能设备晶振.
订购热线：0755-27876565
Silicon品牌|500DLAA125M000ACF|6G无线通信晶振,Silicon晶振,Si500D有源晶振,500DLAA125M000ACF晶振,LVDS输出晶振,石英晶体振荡器,进口贴片晶振,SMD晶振,5032mm晶振,频率125MHz,电压2.5V,频率稳定性150ppm,工作温度0~70°C,低抖动晶振,无铅环保晶振,高可靠性晶振,6G无线通信晶振,调制解调器晶振,医疗电子设备晶振,智能设备晶振.
Silicon品牌|500DLAA125M000ACF|6G无线通信晶振特点：
-无石英，无MEMS，无锁相环
-从0.9到200mhz的任意输出频率
-缩短交货期
-优异的温度稳定性(±20 ppm)
-高度可靠的启动和运行
-抗冲击、抗振动能力强
-低抖动:<1.5 ps rms
-0至85°C的操作包括在高温环境下的10年老化
-足迹与工业标准3.2 x 5.0 mm xo兼容
-支持CMOS、SSTL、LVPECL、LVDS、HCSL等版本
-驱动程序停止、三状态或下电操作
-符合RoHS标准
-1.8, 2.5, 3.3 V选项
-低功耗
-比竞争对手的晶体解决方案高出10倍以上的配合率
Silicon品牌|500DLAA125M000ACF|6G无线通信晶振规格表
(RTERM = 100 Ω diff)3
Parameters
Condition
Si500D
Frequency Range
125MHZ
Frequency Stability
±150ppm
Operating Temperature
Commercial
0°C~+70°C
Extended commercial
0°C~+85°C
Storage Temperature
-55°C~+125°C
Supply Voltage
2.5V
Supply Current
LVDS
16.5 mA Max
Output Symmetry
VDIFF = 0
46 – 13 ns/TCLK% Min
54 + 13 ns/TCLK% Max
Rise and Fall Times (20/80%)3
LVPECL/LVDS
460ps Max
LVDS Output Option (2.5/3.3 V)
Mid-level
1.26V Max
Diff swing
0.45 VPK Max
Return From Powerdown Time
2 ms Max
Period Jitter (1-sigma)
Non-CMOS
2 ps RMS Max
CMOS, CL = 7 pF
3 ps RMS Max
Integrated Phase Jitter
1.0 MHz – min(20 MHz,
0.4 x FOUT),non-CMOS
1 ps RMS Max
1.0 MHz – min(20 MHz,
0.4 x FOUT),CMOS format
1.5 ps RMS Max
Silicon品牌|500DLAA125M000ACF|6G无线通信晶振尺寸图
