EPSON现可为汽车电子提供新型有源晶振SPXO,SG-8201CJA44.5450M-TJHPA0高品质车载6G设备晶振，精工爱普生公司(TSE: 6724，“爱普生”)已经开始出货SG-8201CJA样品，这是爱普生具有CMOS输出的石英晶体振荡器(SPXO)系列的新成员，用于汽车应用。SG-8201CJA提供高稳定性和低抖动2，是一款简单封装的普通有源晶振spxo，通常尺寸为2.0 mm x 1.6 mm x 0.6 mm。

Seiko Epson Corporation (TSE: 6724, "Epson") has begun shipping samples of the SG-8201CJA, a new addition to Epson's lineup of crystal oscillators (SPXO) with CMOS output1 for automotive applications. Offering high stability and low jitter2, the SG-8201CJA is a simple packaged SPXOs that typically measures 2.0 mm x 1.6 mm x 0.6 mm.

EPSON现可为汽车电子提供新型有源晶振SPXO,SG-8201CJA44.5450M-TJHPA0高品质车载6G设备晶振，自动驾驶(AD)中的应用，如激光雷达(LiDAR)和先进驾驶辅助系统(ADAS)中的车载摄像头，由于需要高无线电频率和高速处理，需要频率在100 MHz范围内的参考时钟。此外，AD和ADAS性能的提高推动了对提供出色稳定性和抖动性能的时钟的需求不断增长。在所有汽车应用中，对小型产品的需求也很强劲。

Applications in autonomous driving (AD), such as light detection and ranging3 (LiDAR) and vehicle cameras in advanced driver-assistance systems (ADAS) require a reference clock with a frequency in the 100 MHz range due to the high radio frequencies and high-speeds handled. Moreover, improvement in AD and ADAS performance has fueled rising demand for clocks that offer excellent stability and jitter performance. Demand is also strong for smaller products in all automotive applications.

与其前身SG-8101CGA一样，新的爱普生晶体支持高达170 MHz的汽车应用输出频率，但它具有50%的频率容限和大约1/25的相位抖动。封装占地面积和立方体积也分别减少了64%和55%。SG-8201CJA符合AEC-Q1004标准，可在高达125℃的环境温度下工作，符合汽车应用的要求，有助于提高汽车的安全性和可靠性。

Like its predecessor, the SG-8101CGA, the new crystal oscillator supports output frequencies as high as 170 MHz for automotive applications, but it has 50% better frequency tolerance and approximately 1/25th the phase jitter. The package footprint and cubic volume are also 64% and 55% smaller, respectively. AEC-Q1004 compliant, the SG-8201CJA operates at ambient temperatures up to 125℃ as required for automotive applications and contributes to automotive safety and reliability.

EPSON现可为汽车电子提供新型有源晶振SPXO,SG-8201CJA44.5450M-TJHPA0高品质车载6G设备晶振，爱普生还开始发货用于工业和消费应用的SG-8200CJ和SG-8201CJ晶体振荡器样品。由此，爱普生为消费者、商业、工业和汽车领域的应用组装了一系列产品。

Epson has also started shipping samples of the SG-8200CJ and SG-8201CJ crystal oscillators for industrial and consumer applications. With this, Epson has assembled a lineup of products for applications in the consumer, commercial, industrial, and automotive segments.

爱普生试图利用其设备技术来实现智能社会。为此，公司将继续为汽车应用开发产品，这些应用要求不妥协的精度和安全性，并提高我们客户产品的性能。

Epson seeks to leverage its device technologies to realize a smart society. Toward this end, the company will continue to develop products for automotive applications in which uncompromising accuracy and safety features are demanded and that enhance the performance of our customers' products.
