FX1960009-19.6608MHz-30PPM-12PF-6035-DIODES,台产石英晶振,紧密的公差和稳定性坚固的结构和优秀的机械抗冲击非常紧凑的SMD包可在胶带和卷;12mm胶带,1000单位FX:无pb和RoHS/绿色兼容F6: RoHS兼容,2垫F6系列玻璃密封和4垫FX系列接缝密封装置采用了封装在6.0 x 3.5mm的封装范围内。这些协议可用于在密集的PCB应用中的表面安装。非常适合磁盘驱动器,PCMCIA,个人电脑和手持电子产品.
FX1960009-19.6608MHz-30PPM-12PF-6035-DIODES
单位 |
FX晶振频率范围 |
石英晶振基本条件 |
|
标准频率 |
f_nom |
19.6608MHZ |
标准频率 |
储存温度 |
T_stg |
-55°C ~ +125°C |
裸存 |
工作温度 |
T_use |
-40°C ~ +85°C |
标准温度 |
激励功率 |
DL |
200μW Max. |
推荐:1μW ~ 100μW |
频率公差 |
f_— l |
±50 × 10-6(标准), |
+25°C 对于超出标准的规格说明, |
频率温度特征 |
f_tem |
±30 × 10-6/-20°C ~ +70°C |
超出标准的规格请联系我们. |
负载电容 |
CL |
8pF ,10PF,12PF,20PF |
超出标准说明,请联系我们. |
FX1960009-19.6608MHz-30PPM-12PF-6035-DIODES
Diodes零件编号 | 制造商 | 系列 | 类型 | 频率 | 频率稳定性 | 频率容差 | 负载电容 |
FX0800015 | Diodes晶振 | FX | MHz 晶体 | 8 MHz | ±20ppm | ±20ppm | 18pF |
FX1200081 | Diodes晶振 | FX | MHz 晶体 | 12 MHz | ±20ppm | ±20ppm | 18pF |
FX1200001 | Diodes晶振 | FX | MHz 晶体 | 12 MHz | ±10ppm | ±10ppm | 12pF |
FX1200080 | Diodes晶振 | FX | MHz 晶体 | 12 MHz | ±30ppm | ±30ppm | 20pF |
FX1220002 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX1220011 | Diodes晶振 | FX | MHz 晶体 | 12.288 MHz | ±30ppm | ±50ppm | 20pF |
FX1430025 | Diodes晶振 | FX | MHz 晶体 | 14.318 MHz | ±30ppm | ±30ppm | 18pF |
FX1430027 | Diodes晶振 | FX | MHz 晶体 | 14.31818 MHz | ±30ppm | ±30ppm | 18pF |
FX1600002 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX1600020 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX1600052 | Diodes晶振 | FX | MHz 晶体 | 16 MHz | ±20ppm | ±20ppm | 18pF |
FX1840027 | Diodes晶振 | FX | MHz 晶体 | 18.432 MHz | ±30ppm | ±30ppm | 20pF |
FX1940008 | Diodes晶振 | FX | MHz 晶体 | 19.44 MHz | ±50ppm | ±50ppm | 13pF |
FX1960009 | Diodes晶振 | FX | MHz 晶体 | 19.6608 MHz | ±30ppm | ±30ppm | 12pF |
FX2000012 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX2000045 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX2000060 | Diodes晶振 | FX | MHz 晶体 | 20 MHz | ±20ppm | ±10ppm | 18pF |
FX2210007 | Diodes晶振 | FX | MHz 晶体 | 22.1184 MHz | ±30ppm | ±30ppm | 20pF |
FX2500059 | Diodes晶振 | FX | MHz 晶体 | 25 MHz | ±20ppm | ±20ppm | 18pF |
FX2500061 | Diodes晶振 | FX | MHz 晶体 | 25 MHz | ±20ppm | ±20ppm | 18pF |
FX2500063 | Diodes晶振 | FX | MHz 晶体 | 25.000625 MHz | ±20ppm | ±20ppm | 18pF |
FX2500068Z | Diodes晶振 | FX | MHz 晶体 | 25 MHz | ±20ppm | ±15ppm | 18pF |
FX2700005 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX2700053 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX2710008 | Diodes晶振 | FX | MHz 晶体 | 27.12 MHz | ±20ppm | ±20ppm | 16pF |
FX4000023 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX1000006 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX1020008 | Diodes晶振 | FX | MHz 晶体 | 10.24 MHz | ±30ppm | ±30ppm | 20pF |
FX1100015 | Diodes晶振 | FX | MHz 晶体 | 11.059 MHz | ±30ppm | ±30ppm | 20pF |
FX0800005 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX0800016 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
FX0800018 | Diodes晶振 | FX | MHz 晶体 | 8 MHz | ±20ppm | ±20ppm | 18pF |
FX6400001 | Diodes晶振 | FX | MHz 晶体 | - | - | - | - |
F60800011 | Diodes晶振 | F6 | MHz 晶体 | 8 MHz | ±30ppm | ±30ppm | 20pF |
F61200041 | Diodes晶振 | F6 | MHz 晶体 | 12 MHz | ±20ppm | ±20ppm | 20pF |
F62500053 | Diodes晶振 | F6 | MHz 晶体 | 25 MHz | ±30ppm | ±30ppm | 10pF |
