日产2012富士晶振,6G通讯设备晶振,FCT2M03276807E1晶振,日本Fujicom晶振公司,富士晶振,高精度晶振,2012晶振,石英晶振,二脚晶振,无源晶振,KHz晶振,贴片晶振,6G通讯专用晶振,6G网络晶振,高品质晶振,FCT-2M晶振,超小尺寸2.0×1.2×0.6 mm,高可靠性环保性能,高频稳定性好,精度高,设计用于自动安装和回流焊,符合RoHS标准/无铅
日产2012富士晶振,6G通讯设备晶振,FCT2M03276807E1晶振
项目 | 技术规格 |
频率 | 32.768kHz |
负载电容 | 6pF, 7pF, 9pF, 12.5pF |
频率容差 | ±20ppm |
工作温度 | -40 ~ +85℃ |
周转温度 | 25±5°C |
频率温度曲线 | (−0.030± 10%) x 10-6/ºC2 |
等效串联电阻最大值 | 90kΩ |
驱动电平(标准) | 0.1µW |
驱动电平(最大) | 1.0µW |
分流电容 | 1.3pF Typ. |
绝缘电阻 | More than 500Mohms at DC100V |
储存温度 | − 55 ~ +125℃ |
老化 | ±3ppm/year |
日产2012富士晶振,6G通讯设备晶振,FCT2M03276807E1晶振
FUJI原厂编码 | 生产商品牌 | 型号 | 类型 | 频率 | 频率容差 | 负载电容 | 工作温度 |
FCT2M03276805W6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | 0°C ~ 70°C |
FCT2M03276807E5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 70°C |
FCT2M03276806Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -40°C ~ 85°C |
FCT2M032768C5E3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -20°C ~ 70°C |
FCT2M03276807E6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 70°C |
FCT2M03276806Y3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -40°C ~ 85°C |
FCT2M03276812U6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -40°C ~ 105°C |
FCT2M03276804D1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -10°C ~ 70°C |
FCT2M03276810U6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 10pF | -40°C ~ 105°C |
FCT2M03276807D5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -10°C ~ 70°C |
FCT2M03276807S5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 75°C |
FCT2M03276812Y1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -40°C ~ 85°C |
FCT2M03276806W3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | 0°C ~ 70°C |
FCT2M03276809I6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -40°C ~ 125°C |
FCT2M03276809W5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | 0°C ~ 70°C |
FCT2M03276806W6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | 0°C ~ 70°C |
FCT2M03276804U6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -40°C ~ 105°C |
FCT2M03276812D1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -10°C ~ 70°C |
FCT2M03276804W3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | 0°C ~ 70°C |
FCT2M03276803W3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | 0°C ~ 70°C |
FCT2M03276812S3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -20°C ~ 75°C |
FCT2M03276803U5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 105°C |
FCT2M03276805P5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -10°C ~ 60°C |
FCT2M03276803P5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -10°C ~ 60°C |
FCT2M03276803I6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 125°C |
FCT2M03276804P5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -10°C ~ 60°C |
FCT2M032768C5R6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -30°C ~ 70°C |
FCT2M03276809P3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -10°C ~ 60°C |
FCT2M032768C5D3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -10°C ~ 70°C |
FCT2M03276805P3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -10°C ~ 60°C |
FCT2M032768C5D5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -10°C ~ 70°C |
FCT2M03276809P5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -10°C ~ 60°C |
FCT2M03276805W1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | 0°C ~ 70°C |
FCT2M032768C5S6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -20°C ~ 75°C |
FCT2M03276807P3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -10°C ~ 60°C |
FCT2M03276806I3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -40°C ~ 125°C |
FCT2M03276812S6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -20°C ~ 75°C |
FCT2M03276805P1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -10°C ~ 60°C |
FCT2M03276806P1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -10°C ~ 60°C |
FCT2M03276806U3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -40°C ~ 105°C |
FCT2M03276806E6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -20°C ~ 70°C |
FCT2M03276807T6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -30°C ~ 85°C |
FCT2M032768C5Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 85°C |
FCT2M03276812P3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -10°C ~ 60°C |
FCT2M032768C5I3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 125°C |
FCT2M03276807E3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 70°C |
FCT2M03276812U3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -40°C ~ 105°C |
FCT2M03276806R6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -30°C ~ 70°C |
FCT2M03276804S3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -20°C ~ 75°C |
FCT2M03276804Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -40°C ~ 85°C |
FCT2M03276804U3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -40°C ~ 105°C |
FCT2M03276807T1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -30°C ~ 85°C |
FCT2M03276804D6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -10°C ~ 70°C |
FCT2M03276812W3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | 0°C ~ 70°C |
FCT2M03276805S6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -20°C ~ 75°C |
FCT2M03276805E5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -20°C ~ 70°C |
FCT2M03276812R3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -30°C ~ 70°C |
FCT2M03276806S6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -20°C ~ 75°C |
FCT2M03276812T3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -30°C ~ 85°C |
FCT2M03276809R5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -30°C ~ 70°C |
FCT2M03276809R6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -30°C ~ 70°C |
FCT2M03276812E3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -20°C ~ 70°C |
FCT2M03276809Y1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -40°C ~ 85°C |
FCT2M03276809Y3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -40°C ~ 85°C |
FCT2M03276806R3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -30°C ~ 70°C |
FCT2M03276806S1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -20°C ~ 75°C |
FCT2M03276805Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -40°C ~ 85°C |
FCT2M03276807Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -40°C ~ 85°C |
FCT2M03276809Y6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -40°C ~ 85°C |
FCT2M03276804S5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -20°C ~ 75°C |
FCT2M032768C5I5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 125°C |
FCT2M03276809S3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -20°C ~ 75°C |
FCT2M03276806E3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -20°C ~ 70°C |
FCT2M03276804T3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -30°C ~ 85°C |
FCT2M03276809D6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -10°C ~ 70°C |
FCT2M03276806T6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -30°C ~ 85°C |
FCT2M03276807T5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -30°C ~ 85°C |
FCT2M03276806T3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -30°C ~ 85°C |
FCT2M03276803E3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -20°C ~ 70°C |
FCT2M032768C5P3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -10°C ~ 60°C |
FCT2M03276803T5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -30°C ~ 85°C |
FCT2M03276812U5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -40°C ~ 105°C |
FCT2M03276807R6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -30°C ~ 70°C |
FCT2M03276807Y1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -40°C ~ 85°C |
FCT2M03276805D3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -10°C ~ 70°C |
FCT2M03276809D1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -10°C ~ 70°C |
FCT2M03276807D6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -10°C ~ 70°C |
FCT2M03276812W6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | 0°C ~ 70°C |
FCT2M03276807S6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 75°C |
FCT2M03276803Y5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 85°C |
FCT2M03276812P5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -10°C ~ 60°C |
FCT2M03276809T3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -30°C ~ 85°C |
FCT2M03276807W6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | 0°C ~ 70°C |
FCT2M03276804Y6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -40°C ~ 85°C |
FCT2M03276806D5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -10°C ~ 70°C |
FCT2M03276812W5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | 0°C ~ 70°C |
FCT2M03276803I3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 125°C |
FCT2M03276805Y6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -40°C ~ 85°C |
FCT2M03276807E1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 70°C |
FCT2M03276809P6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -10°C ~ 60°C |
FCT2M03276809E6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -20°C ~ 70°C |
FCT2M03276807Y3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -40°C ~ 85°C |
FCT2M032768C5W5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | 0°C ~ 70°C |
FCT2M03276803S3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -20°C ~ 75°C |
FCT2M032768C5U3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 105°C |
FCT2M03276812E1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -20°C ~ 70°C |
FCT2M03276809E5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 9pF | -20°C ~ 70°C |
FCT2M03276805T1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 5pF | -30°C ~ 85°C |
FCT2M03276812T6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -30°C ~ 85°C |
FCT2M03276807R1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -30°C ~ 70°C |
FCT2M03276806S3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 6pF | -20°C ~ 75°C |
FCT2M032768C5T6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -30°C ~ 85°C |
FCT2M03276807S1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 7pF | -20°C ~ 75°C |
FCT2M03276804D5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -10°C ~ 70°C |
FCT2M03276812R5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12pF | -30°C ~ 70°C |
FCT2M03276803U3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 105°C |
FCT2M03276803Y3 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 3pF | -40°C ~ 85°C |
FCT2M032768C5I6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 125°C |
FCT2M032768C5Y1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 85°C |
FCT2M03276804W5 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | 0°C ~ 70°C |
FCT2M032768C5U6 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 12.5pF | -40°C ~ 105°C |
FCT2M03276804R1 | Fuji晶振 | FCT-2M | kHz Crystal (Tuning Fork) | 32.768 kHz | - | 4pF | -30°C ~ 70°C |
