ECS-2033-240-BN-TR3,ECS-2033振荡器,高密度晶振

原厂型号Originalmodel：	ECS-2033-240-BN-TR3	品牌brand：	ECS晶振
Manufacturer品牌	ECS晶振	OperatingTemperature温度	-40°C ~ 85°C
Series型号	ECS-2033	Current-Supply(Max)	13mA
Type类型	XO (Standard)	PackageHeight高度	0.90mm
Frequency频率	24 MHz	Termination脚位	4 pad
输出方式Output：	CMOS	PackageType封装类型	4-SMD
Voltage-Supply电压	3.3V	Packaging包装	TapeandReel
FrequencyStability频率稳定度	±50ppm	安装方式Installation：	Surfacemount
Size/Dimension尺寸	2.50mm x 2.00mm	最小包装数MPQ：	3000

ECS-2033

ECS-2033-240-BN-TR3,ECS-2033振荡器,高密度晶振

ECS-2333-160-BN-TR	ECS晶振	ECS-2333	XO	16 MHz	HCMOS	3.3V	±50ppm
ECS-2033-250-BN	ECS晶振	ECS-2033	XO	25 MHz	CMOS	3.3V	±50ppm
ECS-2333-500-BN-TR	ECS晶振	ECS-2333	XO	50 MHz	HCMOS	3.3V	±50ppm
ECS-2018-270-BN	ECS晶振	ECS-2018	XO	27 MHz	HCMOS	1.8V	±50ppm
ECS-2018-240-BN-TR3	ECS晶振	ECS-2018	XO	24 MHz	HCMOS	1.8V	±50ppm
ECS-2033-500-BN	ECS晶振	ECS-2033	XO	50 MHz	CMOS	3.3V	±50ppm
ECS-3963-250-BN-TR	ECS晶振	ECS-3963-BN	XO	25 MHz	HCMOS	3.3V	±50ppm
ECS-2033-240-BN	ECS晶振	ECS-2033	XO	24 MHz	CMOS	3.3V	±50ppm
ECS-2033-120-BN	ECS晶振	ECS-2033	XO	12 MHz	CMOS	3.3V	±50ppm
ECS-327MVATX-2-CN-TR3	ECS晶振	ECS-327MVATX	XO	32.768 kHz	CMOS	1.6V ~ 3.6V	±25ppm
ECS-327MVATX-3-CN-TR	ECS晶振	ECS-327MVATX	XO	32.768 kHz	CMOS	1.6V ~ 3.6V	±25ppm
ECS-3225MV-260-CN-TR	ECS晶振	ECS-3225MV	XO	26 MHz	HCMOS	1.62V ~ 3.63V	±25ppm
ECS-3225MV-240-BN-TR	ECS晶振	ECS-3225MV	XO	24 MHz	HCMOS	1.62V ~ 3.63V	±50ppm
ECS-2018-250-BN	ECS晶振	ECS-2018	XO	25 MHz	HCMOS	1.8V	±50ppm
ECS-3225MV-500-CN-TR	ECS晶振	ECS-3225MV	XO	50 MHz	HCMOS	1.62V ~ 3.63V	±25ppm
ECS-3225MV-120-BN-TR	ECS晶振	ECS-3225MV	XO	12 MHz	HCMOS	1.62V ~ 3.63V	±50ppm
ECS-3225MV-250-CN-TR3	ECS晶振	ECS-3225MV	XO	25 MHz	HCMOS	1.8V ~ 3.3V	±25ppm
ECS-3225MV-160-BN-TR	ECS晶振	ECS-3225MV	XO	16 MHz	HCMOS	1.62V ~ 3.63V	±50ppm
ECS-3225MV-500-BN-TR	ECS晶振	ECS-3225MV	XO	50 MHz	HCMOS	1.62V ~ 3.63V	±50ppm
ECS-3225MV-160-CN-TR	ECS晶振	ECS-3225MV	XO	16 MHz	HCMOS	1.62V ~ 3.63V	±25ppm
ECS-2520MV-160-CN-TR	ECS晶振	ECS-2520MV	XO	16 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2520MV-250-CN-TR	ECS晶振	ECS-2520MV	XO	25 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2520MV-250-BN-TR	ECS晶振	ECS-2520MV	XO	25 MHz	HCMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MV-240-BN-TR	ECS晶振	ECS-2520MV	XO	24 MHz	HCMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MV-120-BL-TR	ECS晶振	ECS-2520MV	XO	12 MHz	HCMOS	1.6V ~ 3.6V	±50ppm
ECS-5032MV-250-CN-TR	ECS晶振	ECS-5032MV	XO	25 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2520MV-480-BN-TR	ECS晶振	ECS-2520MV	XO	48 MHz	HCMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MV-080-CN-TR	ECS晶振	ECS-2520MV	XO	8 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2033-240-BN-TR3	ECS晶振	ECS-2033	XO	24 MHz	CMOS	3.3V	±50ppm
ECS-2033-250-BN-TR3	ECS晶振	ECS-2033	XO	25 MHz	CMOS	3.3V	±50ppm
ECS-2520MV-500-BL-TR	ECS晶振	ECS-2520MV	XO	50 MHz	HCMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MV-480-CN-TR	ECS晶振	ECS-2520MV	XO	48 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-3225MV-250-CN-TR	ECS晶振	ECS-3225MV	XO	25 MHz	HCMOS	1.62V ~ 3.63V	±25ppm
ECS-5032MV-240-CN-TR	ECS晶振	ECS-5032MV	XO	24 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-3953M-480-B-TR	ECS晶振	ECS-3953M	XO	48 MHz	HCMOS	3.3V	±50ppm
ECS-5032MV-200-CN-TR	ECS晶振	ECS-5032MV	XO	20 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2520MVQ-250-CN-TR	ECS晶振	ECS-2520MVQ	XO	25 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-5032MV-500-CN-TR	ECS晶振	ECS-5032MV	XO	50 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-3963-040-BN-TR	ECS晶振	ECS-3963-BN	XO	4 MHz	HCMOS	3.3V	±50ppm
ECS-2520MVLC-075-BN-TR	ECS晶振	ECS-2520MVLC	XO	7.5728 MHz	CMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MVLC-081.92-BN-TR	ECS晶振	ECS-2520MVLC	XO	8.192 MHz	CMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MVLC-120-CN-TR	ECS晶振	ECS-2520MVLC	XO	12 MHz	CMOS	1.6V ~ 3.6V	±25ppm
ECS-2520MVLC-271.2-BN-TR	ECS晶振	ECS-2520MVLC	XO	27.12 MHz	CMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MVLC-049-BN-TR	ECS晶振	ECS-2520MVLC	XO	4.9152 MHz	CMOS	1.6V ~ 3.6V	±50ppm
ECS-2520MVLC-250-CN-TR	ECS晶振	ECS-2520MVLC	XO	25 MHz	CMOS	1.6V ~ 3.6V	±25ppm
ECS-3951M-160-B-TR	ECS晶振	ECS-3951M	XO	16 MHz	HCMOS	5V	±50ppm
ECS-5032MV-122.8-CN-TR	ECS晶振	ECS-5032MV	XO	12.288 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-327MVATX-7-CN-TR	ECS晶振	ECS-327MVATX	XO	32.768 kHz	CMOS	1.6V ~ 3.6V	±25ppm
ECS-5032MV-1250-CN-TR	ECS晶振	ECS-5032MV	XO	125 MHz	HCMOS	1.6V ~ 3.6V	±25ppm
ECS-2018-143-BN	ECS晶振	ECS-2018	XO	14.31818 MHz	HCMOS	1.8V	±50ppm
ECS-327ATQMV-AS-TR	ECS晶振	ECS-327ATQMV	XO	32.768 kHz	CMOS	1.62V ~ 3.63V	±100ppm
ECS-3963-120-BN-TR	ECS晶振	ECS-3963-BN	XO	12 MHz	HCMOS	3.3V	±50ppm
ECS-3225MVQ-1000-CN-TR	ECS晶振	ECS-3225MVQ	XO	100 MHz	HCMOS	1.7V ~ 3.6V	±25ppm
ECS-3953M-250-B-TR	ECS晶振	ECS-3953M	XO	25 MHz	HCMOS	3.3V	±50ppm
ECS-3963-250-AU-TR	ECS晶振	ECS-3963	XO	25 MHz	HCMOS	3.3V	±100ppm
ECS-3953M-500-BN-TR	ECS晶振	ECS-3953M-BN	XO	50 MHz	HCMOS	3.3V	±50ppm
ECS-3951M-160-BN-TR	ECS晶振	ECS-3951M-BN	XO	16 MHz	HCMOS	5V	±50ppm
ECS-3953M-250-BN-TR	ECS晶振	ECS-3953M-BN	XO	25 MHz	HCMOS	3.3V	±50ppm
ECS-3953M-120-BN-TR	ECS晶振	ECS-3953M-BN	XO	12 MHz	HCMOS	3.3V	±50ppm
ECS-3953M-018-BN-TR	ECS晶振	ECS-3953M-BN	XO	1.8432 MHz	HCMOS	3.3V	±50ppm
