麦特伦皮晶振,M1004S156 24.000000插件晶振,49S室外6G基站晶振

yijin-1

麦特伦皮晶振,M1004S156 24.000000插件晶振,49S室外6G基站晶振，美国麦特伦皮晶振公司，MtronPTI晶振，石英晶振，插件晶振，二脚晶振，49S晶振，进口晶振，ATS晶振，高品质晶振，耐环境晶振，耐冲击晶振，无源晶振，环保无铅晶振，产品可靠，用户指定公差，符合国际标准

yijin-3

麦特伦皮晶振,M1004S156 24.000000插件晶振,49S室外6G基站晶振

参数	Symbol	Min.	Typ.	Max.	Units	Condition/Notes
频率范围	F	3.579545		72	MHz
频率容差	F/F	-30		+30	ppm
频率稳定度	AF/F	-50		+50	ppm	See Note 1
工作温度范围	TA	- 10		+70	°C
储存温度范围	TS	-55		+125		°C
老化			±5	±5
负载电容	L		18		pF	See Note 2
分流电容	CO			7	pF
驱动电平	DL	25	100	500	W
绝缘电阻	IR	500			MOhms
机械冲击	MIL-STD-202, Method 213, C (100 g’s)
振动	MIL-STD-202, Method 201 & 204 (10 g’s from 10-2000 Hz)
热循环	MIL-STD-883, Method 1010, B (-55°C to 125°C, 15 min dwell, 10 cycles)
密封性	MIL-STD-202, Method 112 (must meet 1 x 10-8)
可焊性	Per EIAJ-STD-002
最大波焊条件	+260°C for 10 secs. Max.

yijin-2

麦特伦皮晶振,M1004S156 24.000000插件晶振,49S室外6G基站晶振

原厂编码	型号	类型	频率稳定度	频率	频率容差
M220168MPJ 156.250000	M220x	XO	±20 ppm	156.25	±20 ppm
1698-065 18.600000	MHO+	XO	±25 ppm	18.6	±10 ppm
XO9085-002	XO9085	OCXO	±100 ppb	100	±100 ppb
XO9085-004	XO9085	OCXO	±100 ppb	100	±100 ppb
M61612GTSN 10.000000	M616x	VCTCXO	±0.5 ppm	10	±1 ppm
M61612JFCN 20.000000	M616x	TCXO	±1 ppm	20	±1 ppm
M61612JTCN 10.000000	M616x	VCTCXO	±1 ppm	10	±1 ppm
M61612LTCN 10.000000	M616x	VCTCXO	±4.6 ppm	10	±1 ppm
M61612MFCN 10.000000	M616x	TCXO	±0.2 ppm	10	±1 ppm
M61613LFSN 50.000000	M616x	TCXO	±4.6 ppm	50	±1 ppm
M61616LTCN 10.000000	M616x	VCTCXO	±4.6 ppm	10	±1 ppm
M61641GFCN 10.000000	M616x	TCXO	±0.5 ppm	10	±1 ppm
M61641GFCN 40.000000	M616x	TCXO	±0.5 ppm	40	±1 ppm
M61642GFCN 24.000000	M616x	TCXO	±0.5 ppm	24	±1 ppm
M61642GFSN 20.000000	M616x	TCXO	±0.5 ppm	20	±1 ppm
M61642GTSN 40.000000	M616x	VCTCXO	±0.5 ppm	40	±1 ppm
M61642JFCN 20.000000	M616x	TCXO	±1 ppm	20	±1 ppm
M61642JFCN 50.000000	M616x	TCXO	±1 ppm	50	±1 ppm
M61642JFSN 10.000000	M616x	TCXO	±1 ppm	10	±1 ppm
M61642JTSN 9.600000	M616x	VCTCXO	±1 ppm	9.6	±1 ppm
M61642KFSN 10.000000	M616x	TCXO	±2 ppm	10	±1 ppm
M61646PTCN 50.000000	M616x	VCTCXO	±0.3 ppm	50	±1 ppm
M61652GFCN 10.000000	M616x	TCXO	±0.5 ppm	10	±1 ppm
M61652GFSN 10.000000	M616x	TCXO	±0.5 ppm	10	±1 ppm
M61812GTSN 10.000000	M168x	VCTCXO	±0.5 ppm	10	±1 ppm
M61812MFSN 16.384000	M618x	TCXO	±0.2 ppm	16.384	±1 ppm
M61812MTSN 16.384000	M618x	VCTCXO	±0.2 ppm	16.384	±1 ppm
M61812PFCN 25.000000	M168x	TCXO	±0.3 ppm	25	±1 ppm
M61812PTCN 24.576000	M168x	VCTCXO	±0.3 ppm	24.576	±1 ppm
M61816GFCN 50.000000	M168x	TCXO	±0.5 ppm	50	±1 ppm
M61816PTCN 50.000000	M168x	VCTCXO	±0.3 ppm	50	±1 ppm
M6181S020 32.000000	M618x	VCTCXO	±0.28 ppm	32	±1 ppm
M61822PFSN 8.192000	M168x	TCXO	±0.3 ppm	8.192	±1 ppm
HPO-310 66.000000	HPO	XO	±5 ppm	66	±5 ppm
HPO-310 77.760000	HPO	XO	±5 ppm	77.76	±5 ppm
HPO-311 112.500000	HPO	XO	±5 ppm	112.5	±5 ppm
HPO-311 25.000000	HPO	XO	±5 ppm	25	±5 ppm
HPO-311 62.208000	HPO	XO	±5 ppm	62.208	±5 ppm
HPO-320 66.000000	HPO	XO	±5 ppm	66	±5 ppm
HPO-320 77.760000	HPO	XO	±5 ppm	77.76	±5 ppm
HPO-321 112.500000	HPO	XO	±5 ppm	112.5	±5 ppm
HPO-321 25.000000	HPO	XO	±5 ppm	25	±5 ppm
HPO-321 62.208000	HPO	XO	±5 ppm	62.208	±5 ppm
XO5085-012R	XO5085	OCXO	±100 ppb	100	±100 ppb
XO5123-034R	XO5123	OCXO	±10 ppb	10	±10 ppb
XO5123-037R	XO5123	OCXO	±10 ppb	10	±10 ppb
XO5123-040R	XO5123	OCXO	±10 ppb	10	±10 ppb
XO5123-060R	XO5123	OCXO	±0.6 ppb	40	±0.6 ppb
XO5123-061R	XO5123	OCXO	±5 ppb	10	±5 ppb
XO5123-064R	XO5123	OCXO	±10 ppb	10	±10 ppb
XO5123-065R	XO5123	OCXO	±0.6 ppb	10	±0.6 ppb
XO5123-070R	XO5123	OCXO	±2 ppb	10	±2 ppb
1485-003 10.000000	M1	XO	±25 ppm	10	±10 ppm
60501-26N-48.000	M1	XO	±25 ppm	48	±25 ppm
1378-003 16.000000	MHO+	XO	±100 ppm	16	±100 ppm
1698-575 66.666700	M2	XO	±50 ppm	66.6667	±50 ppm
60551-43N 16.384000	M2	XO	±100 ppm	16.384	±100 ppm
M2001S038 50.000000	M2	XO	±50 ppm	50	±50 ppm
M2002S031 66.000000	M2	XO	±50 ppm	66	±50 ppm
M2002S041 16.384000	M2	XO	±100 ppm	16.384	±100 ppm
M2002S220 39.995800	M2	XO	±50 ppm	39.9958	±50 ppm
M2002S294 40.000000	M2	XO	±100 ppm	40	±100 ppm
M2002S295 60.000000	M2	XO	±100 ppm	60	±100 ppm
M2002S429 16.000000	M2	XO	±100 ppm	16	±100 ppm
M2002S454 40.000000	M2	XO	±50 ppm	40	±50 ppm
M2002S455 12.000000	M2	XO	±50 ppm	12	±50 ppm
M2002S654 50.000000	M2	XO	±100 ppm	50	±100 ppm
M2002S656 99.000000	M2	XO	±100 ppm	99	±100 ppm
M2002S709 43.200000	M2	XO	±100 ppm	43.2	±100 ppm
M2002S725 19.660800	M2	XO	±100 ppm	19.6608	±100 ppm
M2002S773 33.000000	M2	XO	±100 ppm	33	±100 ppm
M2002S833 10.000000	M2	XO	±100 ppm	10	±100 ppm
M2002T012 50.000000	M2	XO	±50 ppm	50	±50 ppm
M2002T171 125.000000	M2	XO	±50 ppm	125	±50 ppm
M2002T179 25.000000	M2	XO	±100 ppm	25	±100 ppm
M2002T186 66.667000	M2	XO	±100 ppm	66.667	±100 ppm
M2002T201 33.333300	M2	XO	±50 ppm	33.3333	±50 ppm
M2002T202 25.000000	M2	XO	±50 ppm	25	±50 ppm
M2002T271 66.666000	M2	XO	±25 ppm	66.666	±25 ppm
M2002T299 33.333000	M2	XO	±50 ppm	33.333	±50 ppm
M2002T301 50.000000	M2	XO	±30 ppm	50	±30 ppm
M210224ULC 500.000000	M210x	XO	±50 ppm	500	±50 ppm
M218TAN 51.840000	M2	XO	±20 ppm	51.84	±20 ppm
M218TCN 100.000000	M2	XO	±20 ppm	100	±20 ppm
M218TCN 125.000000	M2	XO	±20 ppm	125	±20 ppm
M218TCN 20.141600	M2	XO	±20 ppm	20.1416	±20 ppm
M218TCN 44.736000	M2	XO	±20 ppm	44.736	±20 ppm
