AEK晶振,A072-151.2M1,进口安克晶振,151.2MHz,石英晶振,7050贴片晶振

Parameter | Unit | Minimum | Typical | Maximum |
Central frequency | MHz | 151 | 151.2 | 151.4 |
Insertion loss | dB | - | - | 1.8 |
Bandwidth at -1.2 дБ | MHz | 7.9 | - | - |
Bandwidth at -40 дБ | MHz | - | - | 26 |
Amplitude ripple | dB | - | - | 1.2 |
Group Delay Ripple | ns | - | - | - |
Ultimate rejection | dB | - | 50 | - |
Operating temperature | °C | -55 | 22 | 85 |
Substrate | - | - | Lithium niobate 49 | - |

AEK晶振,A072-151.2M1,进口安克晶振,151.2MHz,石英晶振,7050贴片晶振
